POS8000
Compact Embedded Box PC
Flytech's POS8000 is a powerful compact embedded Box PC built with a die-casting front cover and impact-resistant top and bottom covers. The space-saving and slim design make this unit a great fit for any space use. It features the advanced I/O ports to help handle all the workloads with efficiency. The fanless and low-power consumption design make the POS8000 an excellent choice for any type of business looking for a cost-effective embedded Box PC solution.
POS 8000
Slim and Fanless Embedded Box PC
Slim and Fanless Embedded Box PC
Quiet Work Environment
Silent with fanless design
Compact Mounting Layout
Wall-mounted and desk-mounted available
by using the mounting brackets
Small but Mighty
Maximize your workspace with a small footprint design
Specifications
| Processor | Intel Bay Trail CPU Celeron J1900 Intel Haswell CPU LGA-1150 |
| Memory | max. up to 8GB (DDR3) |
| Storage | 1x 512G SSD or 2x 500GB HDD |
| Supported OS | Windows 10 IoT Enterprise (64bit) |
| Graphic Engine | Intel HD Graphics DX11 |
| Expansion | PCI-E Slot |
| Power Adapter | Internal ATX 250W |
| EMC & Safety | FCC Class B, CE Mark, LVD |
| Operating Temperature | 0°C ~ 35°C (32°F ~ 95°F) |
| Storage Temperature | -20°C ~ 60°C (-4°F ~ 140°F) |
| Humidity | 20% ~ 85% RH non-condensing |
| Weight | 1.9 kg (4.2 lbs) |
| Dimensions | 270 x 220 x 50 mm (10.6" x 8.7" x 2.0") |
| External I/O Ports | USB Serial Port LAN Cash Drawer VGA Display Port Audio Line-out Parallel Port PS/2 Kensington Lock |
| Options | Powered USB + LAN Wireless LAN Wall Mount Kit |
